Details
BUILT TO FLY
Take control. Don't accept compromises. Oiz isn't down-country or trail; this is a 120mm XC race machine that looks as good as it rides. Modern geometry and clever suspension, designed from the start around 120mm, bring extra fun to every ride without compromising weight or efficiency. Simply put, Oiz is the fastest XC bike to leave our factory in over 180 years.
Frame Size | S | M | L | XL |
---|---|---|---|---|
Height (in) | 61.1" - 66.9" | 65" - 70.9" | 70.1" - 74.8" | 72.8" - 78" |
Height (cm) | 155 - 170 | 165 - 180 | 178 - 190 | 185 - 198 |
Specs
Pedals | Sold Separately |
---|---|
Fork | Fox 34 Float SC Performance 120 Grip Remote Push to Lock QR15x110 |
Chain | Shimano M6100 |
Frame | Orbea Oiz Carbon OMR, Fiberlink, Boost, BSA, SIC, UFO, I-line shock |
Tires | Maxxis Rekon Race 2.40" WT 120 TPI Exo TLR |
Brakes | Shimano M6100 Hydraulic Disc |
Saddle | Selle Italia Model X FecAlloy Rail 145x248mm |
Wheels | Alloy, Tubeless, 25c, 32H |
Headset | Alloy 1-1/2", Black Oxidated Bearing |
Crankset | Shimano MT511 32t |
Seatpost | OC Mountain Control MC21, 31.6mm, Dropper |
Shifters | Shimano Deore M6100 I-Spec EV |
Rear Derailleur | Shimano SLX M7100 SGS Shadow Plus |
Cassette/Freewheel | Shimano CS-M6100 10-51t 12-Speed |
* Subject to change without notice.
